Author: Subject: MT75 rear mainshaft bearing fitting..
r1_pete

posted on 12/12/19 at 07:33 PM Reply With Quote
MT75 rear mainshaft bearing fitting..

I have a bit of a concern over the rear mainshaft bearing orientation, on the 4wd box I stripped the open side of the bearing was facing the gearbox, on the 2wd box, the bearing had the closed side was facing the gearbox.

From what I can see, if I fit the closed side towards the gearbox, the bearing will run dry, as there is little to no oil feed to the rearmost housing where the speedo drive is.

the front bearing fits closed side to gearbox, but, the housing has slots for oil feed.

can anyone tell me the correct orientation of the rear bearing?

cheers.

Pete.

View User's Profile E-Mail User View All Posts By User U2U Member
fregis

posted on 12/12/19 at 08:04 PM Reply With Quote
Dont remember clearly original setup, but bearing cover metal? it still have gap, bearing will get oil

[Edited on 12/12/19 by fregis]





Never be afraid to do what you are insolvent, remember: amateurs built the ark - Professionals built the Titanic.

View User's Profile Visit User's Homepage View All Posts By User U2U Member
r1_pete

posted on 12/12/19 at 08:41 PM Reply With Quote
Cheers, this is the bearing, the other side is open, just the plastic ball spacer ring.

Mt75 msr bearing
Mt75 msr bearing

View User's Profile E-Mail User View All Posts By User U2U Member
r1_pete

posted on 12/12/19 at 09:30 PM Reply With Quote
Sorted, just re examined the bearing with a light, the plastic side is sealed, the metal side has a clearance where oil gets in, so must be metal side towards gearbox.
View User's Profile E-Mail User View All Posts By User U2U Member
