mark_mcd
|
| posted on 6/4/07 at 05:08 PM |
|
|
K-series In An Indy?
Has anyone done this? It seems a 1.4 k-series engine would be a good engine for the car on paper at least... Lightweight, cheap (apart from the
bellhousing kit...), similar power to stock pinto, revvy and would be cheaper for me to insure I would imagine... Caterham use it in their
Classic.
Would MK sort me out with mounts etc? Could I get away with using no bonnet scoop?
Cheers
[Edited on 6/4/2007 by mark_mcd]
|
|
|
|
|
Humbug
|
| posted on 6/4/07 at 05:37 PM |
|
|
I've got a 1.4 with standard ECU and inlet manifold, even an exhaust with a cat!. The Stuart Taylor has a low bonnet line, so I ended up with a
small scoop.
I got custom mounts made up having made templates from wood.
GeoffT recently converted from Xflow to K-series on throttle bodies.
Not sure if anyone's got a K-series in an Indy, but Hammerhead is/was doing it, I think.
[Edited on 06.04.2007 by Humbug]
|
|
|
Hammerhead
|
| posted on 6/4/07 at 05:37 PM |
|
|
Hi, I am putting the 1.8 k in an indy. It has been a real ball ache for me, but I have managed to get it to the stage where I am about to put it in
the chassis and design the mountings.
MK don't make mountings at the mo, but I said I would give them a copy of my patterns once I had mine fitted.
You will need the bellhousing, got mine for about £100 from blatchat. (caterham forum)
I also got a shortened sump.
You will need the ecu, 5as unit and key fob from the doner car to make it worthwhile. Alot of people say that the 1.4 is a good doner for a 7 type
car.
If you want to know anything else don't hesitate to ask me.
Steve.
|
|
|
snoopy
|
| posted on 6/4/07 at 06:15 PM |
|
|
you mean like this

rover
its a doddle to fit you keep the existing throttle housing you dont have to modify sump or move alternator you even keep original alterntor belt
engine mounts are dead easy as is exhaust its straight out above chassis top rail only expence is bellhousing and starter motor but you will need a
bonnet buldge though
and as they say on blue peter heres one i made earlier
.jpg)
[Edited on 6/4/07 by snoopy]
|
|
|
stevec
|
| posted on 6/4/07 at 08:57 PM |
|
|
Snoopy,
Your back, hooray
Steve.
|
|
|
Hammerhead
|
| posted on 7/4/07 at 09:40 AM |
|
|
Snoopy, when you say engine mounts are 'dead easy' could you elaborate on that?
Cheers.
|
|
|
snoopy
|
| posted on 8/4/07 at 07:13 AM |
|
|
was a while ago now mounts were hade from flat plate and 50mm box much like mk pinto ones but longer and using if i can rember the holes arrowed in
the pictures

k seris 1
.jpg)
[Edited on 8/4/07 by snoopy]
|
|
|
mark_mcd
|
| posted on 8/4/07 at 05:48 PM |
|
|
quote:
Originally posted by snoopy
you mean like this
rover
its a doddle to fit you keep the existing throttle housing you dont have to modify sump or move alternator you even keep original alterntor belt
engine mounts are dead easy as is exhaust its straight out above chassis top rail only expence is bellhousing and starter motor but you will need a
bonnet buldge though
and as they say on blue peter heres one i made earlier
[Edited on 6/4/07 by snoopy]
Excellent . Ideally it would be good if I could order the kit and have MK make the mounts for me so if they have done it before thats great. I
would be keeping standard ecu etc.
So basically the only thing that needs done to this engine would be to sort the bellhousing and starter motor? What starter motor was used? How much
for a bellhousing? How much sump clearance do you have with an unmodded sump?
Off the top of my head I read before that the 1.4 and maybe 1.6 engines need something drilled?
Thanks guys
|
|
|
snoopy
|
| posted on 8/4/07 at 09:16 PM |
|
|
some of these questions im unable to answer as the bellhousing clutch and starter motor were provided for us by company they were built for but you
can ask him yourself
here
as to the sump clarance then its fine
|
|
|
Hammerhead
|
| posted on 8/4/07 at 10:30 PM |
|
|
thanks snoopy. Thats a great help.
I think the 1.4 and 1.6 need the crank drilling to allow the type 9 input shaft to fit. Also you will need the type 9 gearbox from a xr4i the one with
the longer input shaft. Guess how i found that one out?
blatchat is a good website for k series questions.
|
|
|
mark_mcd
|
| posted on 9/4/07 at 03:22 PM |
|
|
quote:
Originally posted by Hammerhead
I think the 1.4 and 1.6 need the crank drilling to allow the type 9 input shaft to fit. Also you will need the type 9 gearbox from a xr4i the one with
the longer input shaft. Guess how i found that one out?
hi, is the crank drilling a big job?
|
|
|
Hammerhead
|
| posted on 10/4/07 at 09:36 AM |
|
|
i don't know. My engine is 1.8 so doesnt need the mod. Best go on www.blatchat.com (.co.uk?) and do a search.
|
|
|
mark_mcd
|
| posted on 10/4/07 at 10:33 AM |
|
|
it seems you cannot register on that site unless you are a member of the club?
|
|
|
StevieB
|
| posted on 11/4/07 at 02:50 PM |
|
|
It's probably an expensive option (but occassionally a pleasant suprise), but Caterham use the 1400 K Series in their Classic and Academy race
cars - they're bound to supply bellhousing's (and gearboxes too, if you have the budget and want a close ratio 6 speeder).
|
|
|
