tom_loughlin
|
 posted on 28/4/05 at 11:54 PM |
|
|
CAD renderings
Just finished a 3d arendering of my car - js case anyones interested, heres a few pics:
you can keep on going forever adding more and more detail, but thought id best stop somewhere
Tom

Rescued attachment Driver Rear View.jpg
|
|
|
|
|
Hellfire
|
| posted on 28/4/05 at 11:57 PM |
|
|
Nice job - those stone tyres look a bit heavy!!
|
|
|
tom_loughlin
|
| posted on 28/4/05 at 11:59 PM |
|
|
and another

Rescued attachment Left Rear View.jpg
|
|
|
scoobyis2cool
|
| posted on 29/4/05 at 12:02 AM |
|
|
That looks really good, what software did you do it in?
By the way, you missed the cycle wings
Pete
It's not that I'm lazy, it's that I just don't care...
|
|
|
tom_loughlin
|
| posted on 29/4/05 at 12:05 AM |
|
|
theres a hard top on the way, but my comp wont upload the pic for some reason...
the cycle wings are in carbon, probably hard to see over the stone tyres
next stop is the headlights and indicators i think
Its been modelled in rhino3d using NURBS, and rendered in flamingo raytrace
[Edited on 29/4/05 by tom_loughlin]
|
|
|
scoobyis2cool
|
| posted on 29/4/05 at 12:16 AM |
|
|
Oh yeah I can see the cycle wings now, silly me!
Is it an accurate model to help you decide dimensions or more an artistic one to help you choose colours, wheels etc? Looks good either way.
Pete
It's not that I'm lazy, it's that I just don't care...
|
|
|
carlgeldard
|
| posted on 29/4/05 at 06:36 AM |
|
|
I can lend you some alloys
Carl
|
|
|
flak monkey
|
| posted on 29/4/05 at 07:37 AM |
|
|
Very nice Tom!
Sera
http://www.motosera.com
|
|
|
JamJah
|
| posted on 29/4/05 at 03:09 PM |
|
|
Very nice.
I am impressed by the latter alloys too.
Personally just feel its an exercise. Unless your doing many changes. So not really my thing though.
|
|
|
MikeR
|
| posted on 29/4/05 at 05:13 PM |
|
|
would it be possible to make a request - ie if i said could i see the body in GTS red and the wings (front and rear) in black would you be able to
render it ?
(its what i'm thinking of for my colour scheme, except i keep panicing it will look crap)
|
|
|
flak monkey
|
| posted on 29/4/05 at 05:50 PM |
|
|
I can provide a locost rendered to what you like...but it doesnt look at pretty as Toms!
David

Rescued attachment test1.jpg
Sera
http://www.motosera.com
|
|
|
flak monkey
|
| posted on 29/4/05 at 05:53 PM |
|
|
And another...
I'm sure Tom will provide you with some better ones though!
[Edited on 29/4/05 by flak monkey]

Rescued attachment test.jpg
Sera
http://www.motosera.com
|
|
|
MikeR
|
| posted on 29/4/05 at 11:23 PM |
|
|
Cheers, thanks for that. I think it does look alright .........
just wish it didn't cost so much for the GRP!
|
|
|
ned
|
| posted on 30/4/05 at 11:21 AM |
|
|
Mike,
i'm going for those colours but with ally sides and rear. i have the bodywork, so i might be able to clamp it in position next week so you can
see what it looks like actually on a car!
otherwise scotlad has that colour scheme on his indy iirc.
HTH
Ned.
ps did you get the harness mounts ok?
beware, I've got yellow skin
|
|
|
MikeR
|
| posted on 30/4/05 at 11:15 PM |
|
|
Not sure if i've got the harness mounts as my lovely company has had me in Croydon all week - impressed, NOT !!!!
Should pick them up from the office on monday on my way back from a friends.
I'd love to see some pics as well
|
|
|
MikeR
|
| posted on 2/5/05 at 04:57 PM |
|
|
Errm, any chance of a rendering with the car having black sides (where the ali goes) seems the company who are likely to supply my GRP don't do
GRP sides and i know i can get the ali sides powder coated.
|
|
|
flak monkey
|
| posted on 2/5/05 at 05:04 PM |
|
|
1

Rescued attachment black1.jpg
Sera
http://www.motosera.com
|
|
|
flak monkey
|
| posted on 2/5/05 at 05:05 PM |
|
|
2

Rescued attachment black2.jpg
Sera
http://www.motosera.com
|
|
|
tom_loughlin
|
| posted on 5/5/05 at 11:35 AM |
|
|
Heres my versions:

Rescued attachment red.jpg
|
|
|
tom_loughlin
|
| posted on 5/5/05 at 11:36 AM |
|
|
and

Rescued attachment black.jpg
|
|
|
tom_loughlin
|
| posted on 7/5/05 at 10:34 AM |
|
|
A more redder red for you mike
Tom

Rescued attachment red.jpg
|
|
|
MikeR
|
| posted on 9/5/05 at 09:58 AM |
|
|
Cheers Tom, so any chance i could see what it would look like with Ali sides and Black sides?
Promise i'll stop after these two
If there is anything i can do in return just ask, this is much appreciated. Hmm, suppose it would be good if we could get a model where you could
change the colours yourself - anyone know how to do it (bit like the westfield site has).
|
|
|
Kitlooney1000
|
| posted on 9/5/05 at 08:58 PM |
|
|
can anyone do a rendering in graphite grey with ac stripes in silver with graphite coloured ten spoke wheels? just want to see what the next one is
going to look like.
would do it myself, but i found it easier to build the real car than to render it on a pc program
Doesnt matter what Sh*t life throws at you, there is always some other poor bugger worse off!!!!!
|
|
|
scoobyis2cool
|
| posted on 9/5/05 at 09:27 PM |
|
|
Could someone do me one with purple bodywork (except for the bonnet which should be black), a bonnet scoop, aeroscreen, 15 inch superleggeras with
avon acb10s, an 'MK' nose grill, stencilling across the boot panel which says "Pete's burn machine", red springs, chrome
wishbones, all leather interior, carbon fibre cycle wings, 4 point harnesses, and a toneaux cover (both on and off)?
Oh and while you're at it, any chance of modelling a photo-realistic Donington Park so that I can see what it would look like on track days?
Pete
It's not that I'm lazy, it's that I just don't care...
|
|
|
tom_loughlin
|
| posted on 12/5/05 at 04:40 PM |
|
|
My comp has just given up on life altogther, so i wont be able to sort any renderings out for the next week or so, or however long the servicers take
to fix it.
will post the pics when its back.
Tom
Pete, send a pic of donnington park, and ill see what i can do
|
|
|
